Product Details:
|
| Turnkey PCBA: | PCB+components Sourcing+assembly+package | Assembly Details: | SMT And Thru-hole, ISO Lines |
|---|---|---|---|
| Lead Time: | Prototype: 15 Work Days. Mass Order: 20~25 Work Days | Testing On Products: | Flying Probe Test, X-ray Inspection, AOI Test, Functional Test |
| Quantity: | Min Quantity: 1000pcs. Prototype, Small Order, Mass Order, All OK | Files We Need: | Assembly: Pick-N-Place File |
| Components Details: | BGA And VFBGA | PCB Panel Size: | Min Size: 0.25*0.25 Inches(6*6mm)，Max Size: 20*20 Inches(500*500mm) |
| Copper Thickness: | 1oz,0.5-2.0 Oz,1-3oz,0.5-5oz,0.5-4oz | Base Material: | FR4, Aluminium, TG, Rogers, CEM-1 |
| Service: | One-stop Service, PCB&PCBA, ODM And OEM | Board Thickness: | 1.6mm, 0.5~3.2mm, 0.2-3.0mm, 0.3~2.5mm, 2.0mm |
| Highlight: | bare die pcb assembly,cem pcb assembly,pcb assembly aoi |
||
PCB & PCBA capability and services:
1. Single-sided, double side & multi-layer PCB with competitive price, good quality and excellent service.
2. CEM-1, FR-4, FR-4 High TG, Aluminum base material.
3. HAL, HAL lead free, Immersion Gold/ Silver/Tin, OSP surface treatment.
4. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.
5. Quantities range from prototype to medium batch production.
6. 100% E-Test.
| No. | Types Of Assembly | File Format | Component Footprinr | Component Package | Testing Produres | Produres | Others |
| 1 | SMT ASSEMBLY | Gerber RS-274X | 0201,0402,0603... | Reels Package | Visual Inspection | Lead-Free(Rohs) | Custom Reflow Profile |
| 2 | SMT & THT Assembly | BOM(.xls,.csv,.xlsx) | BGA,QFN,QFP,PLCC | Cut Tape Package | X-Ray Inspection | Leaded Solder | Standard Reflow Profile |
| 3 | 2 sided SMT,THT Assembly | Pick-N-Place/XY file | SOIC,POP...Connectors | Tube and Tray | AOI,ICT(In-Circuit Test) | Reflow Soldering | Smallest Size:0.2"x0.2" |
| 4 | Mixed Assembly | ... | Small Pitch of 8 Mils | Loose parts and bulk | Functional Testing | Wave Soldering | Largest Size:15"x"20 |
1. Program and functional test and package by Free.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.
3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.
4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001,IATF16949
Q: What files do you use in PCBA fabrication?
A: Gerber or Eagle, BOM listing, PNP and Components Position.
Q: Is it possible you could offer sample?
A: Yes, we can custom samples for your testing before mass production.
Q: How much time could I get the quotation after sent Gerber, BOM and test procedure?
A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.
Q: How can I know the process of my PCBA production?
A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing.
Q.What is the warranty?
The warranty is 2years.
